Electronics! Falling into the geek rabbit hole.

[basinbeater]

I have fallen down a rabbit hole lately. It's not the first rabbit hole, and it certainly won't be the last rabbit hole. But it's a cool one!

It really got kick started from installing a subwoofer in the wife's land cruiser, and then going crazy building a stereo system on the cheap for the Porsche,



and I've continued messing around with car stereo stuff on my BMW pretty much non stop since then. I found a really cool amp for sale, and I bought it, and I got home.... and it didn't work. I was kind of pissed, but I decided I would fix it. So lots of googling, and researching, (helps take attention away from fucked up news as well) and I learned how an AB class amplifier works, and how to troubleshoot and diagnose.



Well, I fixed that amp. Then I fixed the old Nakamichi receiver I had laying around. Then I fixed an old Pioneer receiver display that wasn't working. Then I signed up for a college level Linear DC circuits course on Coursera so I can actually learn wtf is going on. My math skills need work.

I decided I wanted to learn to build my own amplifier. I want to design my own circuitry, and build an attractive powerful quality sounding home amplifier. So I am on the first steps. I have built a couple of different small DC to AC to DC power supply circuits. I have built a couple of small basic amplifiers using an operational amplifier chip, to learn how different components interact with the audio signal. Kids think it is fun too. They like pressing wires into the breadboard and seeing waves pop up on the oscilloscope.

I recently found the matching mono amp for the 4 channel one I already fixed, and it needs to be repaired too.... So learning about Class D amplifiers.

Stuff is pretty cool. Fun.

Any other geeks wanna share their projects? It's be cool to find a couple other geeks on here that I could learn a thing or two from.

[MontuckyFried]

That's badass! Have any soldering tips? That's def one of my weaknesses but I really want to get better at it. SO many things get thrown away that could be fixed but sadly electronics repair is quickly becoming a lost art. Definitely something I want to pursue more but time has been my enemy with the hobby. Good post, basin. Very motivating.

[basinbeater]

Well, for soldering, a clean tip, and an iron that gets hot enough make it much easier. I've been soldering stuff since I was a kid, mainly for rc car stuff. My cheapo one just died. So Amazon is bringing me a fancier temp adjustable one with an adjustable hot air rework station (for surface mount stuff). Stoked. Just find something broken and practice putting stuff on, taking it off, cleaning it up, etc...

sent from Utah.

[abraham]

Well, for soldering, a clean tip, and an iron that gets hot enough make it much easier. I've been soldering stuff since I was a kid, mainly for rc car stuff. My cheapo one just died. So Amazon is bringing me a fancier temp adjustable one with an adjustable hot air rework station (for surface mount stuff). Stoked. Just find something broken and practice putting stuff on, taking it off, cleaning it up, etc...

sent from Utah.

If you're doing old and modern stuff check for pb free or pb solder on your boards. Mixing the two can create an alloy that melts at crazy low temperature, ~90C if I recall. It's pretty easy for home use to just use two different tips if you're good about organization

[basinbeater]

Ah. I was not aware. I knew there was leaded and unleaded, but didn't know they have problems when they mix. Good looking out!

Here is one project I completed....
Diamond Audio d5 600.4. was only producing sound from channels 3 and 4. So at least I had a functional side to base things off. Ended up being a blown driver transistor. And a couple resistors that also fried. After replacing them, it came back to life.

https://youtu.be/yI_8fTZE-nc

The nakamichi, I was able to tackle with the tektronix oscilloscope I recently purchased.
Seemed to function normal, good voltages at all the rails and stuff, but no sound. So I started tracking the input signal with the scope. I use a simple signal generator app on the phone to put a clean wave in, and I started tracking the signal until it got lost at the input selector switch. Clean switch, works great now.

Then the pioneer, that one was easy, I pulled the front apart and when twisting, the display would occasional light up. Sure enough, cracked solder joints.

It's funny how sometimes you just go on a roll.


sent from Utah.

[gravitylover]

I have some old equipment that could use a little TLC too. I'd particularly like to get at least one of the old tape decks spinning at the right speed so I can hook up a way to digitise about 500 (more?) old live tapes. Winter project...

[Meathelmet]

With that amount of wires, circuits, soldering and remotes, I think DHS will contact you soon for...job opportunities?

[goldengatestinx]

I have fallen down a rabbit hole lately. It's not the first rabbit hole, and it certainly won't be the last rabbit hole. But it's a cool one!

It really got kick started from installing a subwoofer in the wife's land cruiser, and then going crazy building a stereo system on the cheap for the Porsche,

[ATTACH=CONFIG]303354[/ATTACH]

and I've continued messing around with car stereo stuff on my BMW pretty much non stop since then. I found a really cool amp for sale, and I bought it, and I got home.... and it didn't work. I was kind of pissed, but I decided I would fix it. So lots of googling, and researching, (helps take attention away from fucked up news as well) and I learned how an AB class amplifier works, and how to troubleshoot and diagnose.

[ATTACH=CONFIG]303352[/ATTACH]

Well, I fixed that amp. Then I fixed the old Nakamichi receiver I had laying around. Then I fixed an old Pioneer receiver display that wasn't working. Then I signed up for a college level Linear DC circuits course on Coursera so I can actually learn wtf is going on. My math skills need work.

I decided I wanted to learn to build my own amplifier. I want to design my own circuitry, and build an attractive powerful quality sounding home amplifier. So I am on the first steps. I have built a couple of different small DC to AC to DC power supply circuits. I have built a couple of small basic amplifiers using an operational amplifier chip, to learn how different components interact with the audio signal. Kids think it is fun too. They like pressing wires into the breadboard and seeing waves pop up on the oscilloscope.

I recently found the matching mono amp for the 4 channel one I already fixed, and it needs to be repaired too.... So learning about Class D amplifiers.

Stuff is pretty cool. Fun.

Any other geeks wanna share their projects? It's be cool to find a couple other geeks on here that I could learn a thing or two from.

Multiple hour long convos with the Radio Shack virgins? It's pretty cool what a few inexpensive components can be made to do.

[wooley12]

Are you lost?

OP, I am in awe of your ability. I have a multimeter and the only function I know how use is a continuity check. I could accomplish that with a battery, some wire and a light bulb from my Christmas tree.

[basinbeater]

Got back into it tonight. I fixed my nakamichi sr4a, (kick ass reciever/amp by the way) and fixed all my other electronic shit, so the other day I went by the local hoarders garage and bough a bunch of stuff.
I got a nakamichi sr2a reciever, same basic stasis circuit as the sr-4a, fewer features, less power. It was inoperative and showed zero signs of life.
I fixed it tonight. Initial diagnosis showed power making it to the lower power rails on the main board, but not to the main power rails for amplification, so no sound. Blown fuses on the power supply board, and a bad bridge rectifier. Replaced them tonight, and voila! Sound! It seems to be fixed. I couldn't figure out why all these wires and diodes were on the bottom of the main board, but according to the diagram, they all seem to be going to the right places, and it all checked out. I think I'm done with that one.
The hoarder also had a nakamichi oms7 top of the line CD player, he said didn't work, seems to work fine. I'll use that with my sr4a. Sounds so gooooood.
He also had a band and Olufsen beomaster 3000 system, complete, reciever, turntable, and speakers. It does not work. Next project I guess after turkey day.

sent from Utah.

[mangle]

Spidey senses are tingling...

A good soldering setup will make your life way better. I have a Hakko FX-951 and a Quick 861DW. Hot air is very much necessary for big surface mount stuff. Scope is an MSO 2024, which has some pretty powerful tools for finding glitches in digital comms.

Audio stuff is a ton of fun. While I was learning about power electronis in college, I had an old seeburg select-o-matic 100 jukebox that I rebuilt in my dorm. It had a full class-A tube amp, and all of the mechanical stuff was controlled by mechanical contacts. Oh, and the death-trap ancient florescent light ballast along with a shaded-pole motor to turn the candy cane things. I'll have to go find some pictures.

These days, I do mostly mixed-signal stuff for mechatronic devices. Traveling with electronics is entertaining to say the least. I had the terminal at Jackson Hole airport evacuated a few years ago.

[basinbeater]

The only mechatronic thing I have ever heard of was the mechatronic cable sleeve into a BMW transmission. I was like, and they leak. fuck that noise. Sild that car and sticking with the manual 6 speeds.

More research is needed. I've been studying up on DC power supply circuits quite a bit. I've made a couple of mini power supplies from a power supply on my bread board. They take the 14vdc or so from the power supply and first produce a square wave ac voltage, then through a bridge rectifier, that spits it out into straight DC positive and negative rails.

Fun stuff.
I need a hot air setup, I bought a cheapo Amazon China special, and it arrived DOA. Cheap Chinese shit. I'll look at the ones you have.

sent from Utah.

[mangle]

If you're not going to use it a ton, look at the Aoyue units. They're loud and will fail with heavy use, but they'll last long enough for you to develop preferences and learn about settings with different solders and components. The quick is a fantastic heavy use unit. It's pretty quiet, though it's got a nasty power converter on the input that'll cause the lights in the room to flicker. I'd also recommend getting a good set of tweezers (Hakko CHP3 and CHP7 from amazon are my two workhorses) and a wire-type tip cleaner. Try a couple different fluxes and see what you like, though try not to breathe it.

Power converters are a ton of fun. They really combine everything you learn in school - everything has to be carefully chosen to make it perform well in the application, and building controllers to keep them stable across a wide range of loads can be obnoxious, especially when you get into something like a switched-cap or SEPIC converter.

[basinbeater]

Another question. What is the best app (that doesn't cost am arm and a leg for android, and pc, for simulating circuits, so I can play digitally and figure out what I want to try to build for real?

sent from Utah.

[mangle]

Another question. What is the best app (that doesn't cost am arm and a leg for android, and pc, for simulating circuits, so I can play digitally and figure out what I want to try to build for real?

I don't know. I would imagine that there are plenty of freeware things that'll keep you entertained. I typically use simulink in matlab (definitely not cheap) and used to use Cadence a long time ago. Several of the microcontroller manufacturers (Microchip in particular) have things like that, but I can't speak to them.

But I can recommend Paul Sherz, Practical Electronics for Inventors. It does assume some math and basic electronics background.
